Turbo Parts No.:3524034, 3590079, 3530628, 3528777, 3545701, 3528793, 3527370
OE No.:3802303, 3530629, 3528778,3530716
Turbo Model:H1E
Turbo Brand:HOLSET
Car Application:CDC Industrial 6CT 1986 ；Cummins Zanello N/A 1997 ；Cummins 6CTA 1991 ；J I CASE 6CT 1986
JACK ID:3-00-3013
Details
CHRA Balancing Test: <0.5Mg.mm / 150000RPM
Shaft wheel material: K418+42CrMo
Compressor wheel material: C355 for normal or 2618 for billet
Bearing Housing material: HT250 Gray Iron and high Ni for shift link arm
Back plate material: ADC12 YL102 or Iron for some big models.
Nozzle ring material: K418
Thrust bearing material：Brass Bar Fluorine Gum
O-ring material: Fluorine Gum
Thrust collar material: 42CrMo
Piston Ring material: W6+ 3Cr13
